QST30-C1050 – General Information
Model: QST30-C1050
Displacement: 30.5 L
Bore * Stroke: N/A
Net Weight (with flywheel & alternator): 3328 kg
Overall Dimension: 1855mm*1327mm*1647mm
Manufacture Plant: Chongqing Cummins Plant
QST30-C1050 – Performance Data
Rated Power: 783 kW/1050HP
Rated Speed: 2100 rpm
Peak Torque/Speed: 4629 N.m @ 1300 rpm
Fuel Consumption @ Rated Power: 218g/Kw.h @ 2100 rpm
QST30-C1050 – Technical Specification
Emission Certification: US EPA Tier 2
Aspiration: Turbocharged and After-cooled
Fuel System: Bosch Electronic
Compression Radio: 15.7:1
Electrical System (Starter Motor/Alternator): 12V/24V
Lowest Starting Temp Without auxiliary system: -12℃
