QSK60-C2500 – General Information
Model: QSK60-C2500
Type: 16 Cylinders, V Type
Displacement: 60L
Bore * Stroke: 159 * 190
Net Weight : 8750 kg
Overall Dimension: 2960mm × 1780mm × 2150mm
Manufacture Plant: Cummins CIC USA Plant
QSK60-C2500 – Performance Data
Rated Power/Speed: 1864 kW/2500HP
Rated Speed: 1900 rpm
Max Torque/Speed: N/A
Fuel Consumption @ Rated Power: 211 g/Kw.h
QSK60-C2500 – Technical Specification
Certification: EPA TIER 4/IMO III
Aspiration: Single-stage Turbocharged Aftercooled
Fuel System: MCRS
Compression Ratio: 15:1
