General Information
Model: ISME308-30
Type: 6 Cylinders in Line
Displacement: 10.8 L
Bore * Stroke: 114 * 144.5
Net Weight (with flywheel & alternator): 940 Kg
Overall Dimension: 1135mm*825mm*1159mm
Manufacture Plant: Dongfeng Cummins Plant
Performance Data
Rated Power/Speed: 226 kW/308HP
Rated Speed: 1900 rpm
Torque/Rated Speed: 1150 N.m @ 1900 rpm
Max Torque/Speed: 1500 N.m @ 1000-1400 rpm
Technical Specification
Certification: Euro III
Aspiration: Turbocharged & Charge Air Cooled
Fuel System: Cummins Fuel System/EMC876
Compression Radio: 17.3:1
Electrical System (Starter Motor/Alternator): 24V (750A)
Lowest Starting Temp Without auxiliary system: -10℃/-25℃
Firing Order: 1-5-3-6-2-4
Cooling Method: Water Cooled+
