| 6ZTAA13-G2 340KW 456HP Generator Engine- General Information |
| Model: 6ZTAA13-G2 (390kw) |
| Type: 6 Cylinders in Line, 4 Stroke Diesel |
| Displacement: 13 L |
| Bore * Stroke: 130 * 163 |
| Net Weight: 1195 Kg |
| Overall Dimension: 2180mm*1360mm*1605mm |
| 6ZTAA13-G2 – Performance Data |
| Rated Output/Speed (1500 rpm): 390 kW/523HP @ 1500 rpm |
| Standby Output/Speed (1500 rpm): 415 kW/557HP @ 1500 rpm |
| Continuous Output/Speed (1500 rpm): 350 kW/470HP @ 1500 rpm |
| Rated Output/Speed (1800 rpm): 390 kW/523HP @ 1800 rpm |
| Standby Output/Speed (1800 rpm): 415 kW/557HP @ 1800 rpm |
| Continuous Output/Speed (1800 rpm): 350 kW/470HP @ 1800 rpm |
| Low Idle Speed: 800-1000 rpm |
| Fuel Consumption @ Rated Power: ≤ 235 g/kW.h |
| 6ZTAA13-G2 – Technical Specification |
| Aspiration Method: Turbocharged/Charge Air Cooled |
| Fuel System: BYC PD Pump/ GAC Governor |
| Governor Type: Electronic, Regulation ≤3% |
| Compression Ratio: 17:1 |
| Electrical System (Starter Motor/Alternator): 24V/900CCA |
| Lowest Starting Temp (Without auxiliary system): -15℃/-30℃ |
| Engine Coolant Volume: 23.1 L |
| Cooling Method: Water Cooled |
| Rated Power: 390 kW (523HP); Rated Speed: 1500 rpm |
| Standby Power: 415 kW (557HP) |
| Packing Details: Dimension: 2180 * 1360 * 1605 mm, G.W: 1400 KG |
Cummins generator engines are utilized across various scenarios and applications, known for their reliability, efficiency, and adaptability. They are widely deployed in industrial settings, commercial buildings for backup power systems, and critical facilities such as data centers and medical institutions. Their capability extends to providing stable power support in remote areas and during emergencies, offering dependable solutions across diverse environments.
